House Kit 263.6 sqm made of CLT Panels – for pre-order only!

Please note that the following images of the completed House are for display purposes only, to the sale of the House Kit we only supply a CLT panel frame and fasteners. Minimum order quantity: from a 1x40ft container. Delivery terms: FCA.

📞 0447 764 768

📧 uk.oxleytrade.com.au@gmail.com

The total area of the set of houses (m2) – 263.6
Living area (sq.m) 196.8
Volume of CLT panels (m3) – 112.10
Weight of a set of CLT panels (tons) – 40 210
Dimensions of a set of houses (m) – 14.90 x 15.730
The dimensions of the CLT panel are 120mm x 1050 mm x 3200 mm.

Loading rates for a container.
The internal volume of a 40-foot container is 67.3-67.8 m3.
The maximum carrying capacity is 24.8-26.8 tons.
The weight of a 40-foot container without cargo is 3,640-4,000 kg.

Immerse yourself in the enchanting blend of luxury and nature with our meticulously crafted wooden structures. With eco-friendly features, these House Kits epitomize sustainable living without compromising on elegance. Choose the eco-house lifestyle that nurtures the planet and elevates your spirit!  Crafted from premium wood, these eco-houses radiate eco-conscious elegance, beckoning you to embrace greener living. Personalize your sanctuary and make unforgettable memories in a space that cherishes both you and the environment.

The home kit includes:
→ fasteners; (Rotoblaas,SPAX).
→ cushioning material;
CLT;
;→ protective impregnation of the outer sides of CLT boards;
→ protective impregnation of the ends in two layers;
→ “TechnoNIKOL” for roof insulation.
→ PVC windows and front door.

Massive wooden structures CLT (450 – 500 kg/m3) are five times lighter than concrete (2650 kg/m3). This is when comparing the same thickness of the structures used. But the coefficient of thermal conductivity of concrete is several times worse than the coefficient of thermal conductivity of wood. Savings on transportation, savings on mechanisms (crane). Dimensions CLT panel – 100 mm x 1050 mm x 3500 mm.

SPECIFICATION OF CLT PANELS

Surface treatment : technical, planed or sanded
Applied adhesive composition formaldehyde-free polyurethane adhesive, not more than 1% of the product weight
Raw wood species spruce, pine, class 1 and 2
Maximum dimensions length up to 6 meters, height up to 3 meters (on request up to 4)
Produced thicknesses 3 cl. (45,85,120) mm. 5 w. (95,130,170,210) mm. Formation under the order is possible
Deformation values up to 0.3mm/meter of product
Humidity chamber drying 12% +/-2%
Fire resistance 0.7-0.8mm/min
Thermal conductivity 0.13 W/mK
Specific heat capacity 2.10 kJ/kg
Product weight 480-500 kg/cu.m.
Bearing capacity of a slab 1m wide
100mm 230-300kN, 150mm 700-780kN,
200mm 1000-1100kN, 300mm 1620-1700kN

Material of construction – solid wood CLT panel is an excellent insulator. CLT-Panels are a modern reliable material.
The structural material CLT has high fire resistance and is classified as a difficult to combustible material.
